Eco-Tractor Workshop

October 26-30, 2017 | Factor e Farm – Maysville, MO (USA)

The Open Source Ecology Eco-Tractor workshop is an immersion experience where we will build a working tractor – and more – over a weekend:

• A Microtractor: A tracked machine that is similar in functionality to a Toro Dingo brand utility machine but has more power. We will use a 16 hp Power Cube – our hydraulic power unit. Because our build system is modular, we can add a second Power Cube to this tractor for a total of 32 hp for more demanding tasks.

• Tractor: A 32-64 hp tractor that is a larger version of the MicroTractor – using many of the same components. As the first team works on the Microtractor, a second team will work on a larger version of the tractor. We will use 2 of the same Power Cubes, for 32 hp. We can add 2 more, for a total of 64 hp.

• Solar Module: The beauty of hydraulic power which we use to drive the tractor is that a small power source can still move a heavy machine – only slower. Thus, a 2000 lb or 6000 lb tractor can still move – and with as much force – on a single solar panel. As such, we will use a solar panel to run a small electric Power Cube – which runs the tractor. This will be our proof of concept that a tractor can do useful operations on solar power – shining new light on the capacity of solar power to fuel agriculture. This leads to automation – where a slow-moving (3 feet per minute) tractor running on solar power can do useful work – such as weeding or pulling chicken tractors.
• Automation Module: Another advantage of hydraulics is that they can be controlled easily via solenoid valves and controllers – in addition to manual control. As such, we will first use a remote control module to guide the tractor – and then let it run autonomously with pre-programmed motion. The first proof of concept will be the tractor driving autonomously in a simple pattern – using an Arduino controller. If time allows, we will implement an automated guidance system with feedback from the environment for avoiding obstacles.

If more than 18 people sign up for the workshop, then we will also build a:

• Charcoal Power Module: Did you know that a gasoline engine can run on charcoal? We will be improving upon our 2015 gasifier prototype to build an improved version. The gasifier produces gas from charcoal to fuel the Microtractor. We will mount the gasifier on the tractor, and fuel the tractor with charcoal gas via the air intake. This will demonstrate that our tractor can run on biomass-derived charcoal, which is a renewable form of energy – relevant in areas where biomass is abundant.

Here is some prior work from 2 years ago for you to see what we have done already. This work takes our initial prototyping much further. The largest machine that we built was 71 hp so far. We did not yet build the 164 hp machine discussed in the video:

During this build, the MictroTractor and Tractor have these specifications:

MicroTractor

• Engine:Duromax 16 hp recoil start gasoline engine. These can be purchased for as little as $229 on Amazon – and have a built-in gas tank and muffler. They are widely available.
• Hydraulic pump: 0.677 cubic inch displacement, 3000 PSI pumps
• Fuel:Gasoline, charcoal, and solar energy
• Solar Power:300W solar panel
• MicroTrac Power: 16 or 32 hp (1 or 2 Power Cubes) on gasoline
• Weight of MicroTrac: 2000 lb
• Size of MicroTrac: 41″ wide, 60″ long, 34″ tall
• Track base: 41″ wide
• Hydraulic Motors: 45.6 cu in displacement, 15,000 in-lb motors
• Machine pulling torque: 7000 lb of drive
• Steering: Track steering, 1 track on each side
• Transmission: Hydraulic fluid power
• Track Drive: 8″ sprocket diameter driving the track chain, direct drive from hydraulic motor
• Loader lift: minimum of 2000 lb lifting power, but tipping point is 750 lb at ground level
• Loader height: 60″ of lift to the bottom pivot of the implement mount
• Implement attachment: Bobcat standard quick attach plate
• Track: 9″ wide, 36″ ground contact distance
• Ground pressure: 3.7 psi
• Idler shafts: 3″ solid steel
• Idler diameter: 10″
• Controller:Arduino
• Hydraulic Solenoids: 10 gallon per minute flow rate, 3000 PSI, 12V DC
• Solar power voltage:24V.
• Solar Power Cube: 5 hp hydraulic drive unit (driven at a small fraction of this power)
• Max Speed:3 Miles per hour.
• Speed on solar power: MicroTrac will go 3 feet per minute, or about 1000 feet per day at 15,000 in lb of motor torque and 7000 lb pulling force
• Height: 3′ tall
• Operator: Walks behind tractor, or rides on platform behind tractor
• Auxiliary hydraulic outlets: 20 GPM hydraulic takeoff
• Hydraulic flow to drive: 20 GPM, 3000PSI
• Hydraulic flow to loaders: 20 GPM, 3000PSI
• Power takeoff: standard 6-spline agricultural hydraulic takeoff motor
• Cost: $4300 materials cost for 32 hp version

Tractor:

• Horsepower: 32-64 hp, (with 2-4 Power Cubes)
• Speed: 3 and 6 mph speeds
• Size: 6′ wide, 7′ long, 6′ tall to top of cab
• Weight: About 5000 lb
• Loader Reach: 108″ to bottom pivot of loader arm
• Steering: Track steering
• Implement Attachment: Bobcat standard quick attach
• Track: 12′ long pads, 2.5″ wide. Total surface contact area per track: 5 square feet.
• Ground pressure: 3.5 psi
• System hydraulic pressure: 1500-3000 PSI, adjustable
• License for all OSE machines:OSE License for Distributive Enterprise. Open source mechanical, open source height controller, 3D printed open source parts; CC-BY-SA-4.0 license, and GPL for control code.

The design focuses on minimizing part count and integrating the design with other machines of the Global Village Construction Set (GVCS). Our heavy equipment is designed to use as many parts in common as possible.

A Scalable, Modular Construction Set for Tractors

To create a Construction Set – we designed a small set of modules that can be reconfigured. The core parts include power cubes, the Universal Rotor, tracks, shafts, idlers, frames, and hydraulics modules. We are designing with the absolute simplicity in mind, such that machines can be maintained for a lifetime of use. Our parts count of about 100 unique parts for the entire tractor is lower than anything available on the market.

LifeTrac 6 Infographic by Jean-Baptiste Vervaeck

Power Cube Infographic by Jean-Baptiste Vervaeck

Gasifier Infographic by Jean-Baptiste Vervaeck

MicroTrac Infographic by Jean-Baptiste Vervaeck

Lowest Unique Part Count in the World

The beauty lies in an absolute minimum number of parts that can be used to build an infinite variety of heavy machines – depending on size, axis configuration, and implements heads. The unique part count is in general around only 100 parts, which is about 5 times less than anything available commercially.

By making our machines simple and universal, we are aiming for the most widely replicated tractor construction set in the world. There are no construction sets for tractors available prior to our work. To develop a great product, we are inviting developers and entrepreneurs to join the OSE Development Team.

This workshop intends build upon OSE’s Extreme Manufacturing approach of rapid building with multiple teams working in parallel on modular components. By simplifying the design and streamlining the build with digitally-fabricated, open source parts – we intend to develop a model where several of our tractors can be produced in a single day by a team of people. Our goal is to develop open source microfactories for distributed production – using the Experience Economy and Social Production.

We are also developing an open source enterprise model for how to run extreme build workshops anywhere in the world. We are publishing our enterprise model openly, with all supporting information that helps people in a successful startup – without reinventing the wheel. We will also be offering 6 week immersion training where strong candidates can learn to replicate our workshops to start a small business.

Workshop Expectations
This workshop is experimental, and not a turnkey product. We have significant experience with the topics covered, but surprises always come up in an experimental build. We have thorough CAD documentation of the machine. We have built 10 prototype tractors already. But surprises do come up in ambitious builds like ours. No matter what – we will build it – and we will drive it. Whether we complete the solar drive option, the charcoal fuel option (gasifier), and the computer vision – is up to us.

While we have done extensive design work, and prototyped the different parts – this workshop is a first complete build. Expect to problem solve – and learn a lot in the process. This is an immersion learning experience in design and build.

While we do not require prior skill to join this workshop – the more skill that we have in the team of participants, the better will be the result. We expect people to work together as a team for a common goal, and we like it when participants teach one another new skills.

The intended audience for this workshop is people who want to get their hands dirty – who are interested in the design and build of hardware. The intended audience is anyone interested in exploring the meaning of Open Source Product Development. We’ve been pioneering techniques of collaborative development for several years.

But be prepared – this is not for the faint-hearted. Our facility is raw and crude – a farm in the middle of nowhere, Missouri. By attending, you are helping us carry out our open source development mission.

Bring a Friend for Free

We also have a 2-for-1 offer . You are welcome to bring one friend or family member with you for free.

Additional Information

For more perspective on the Global Village Construction Set, see the Global Village Construction Set:

Open Source Product Development Invitation

Workshop immersion involves concept and practice, and includes a crash course on Open Source Ecology. Participants become engaged in a part of OSE’s development process, where we produce open source blueprints for the infrastructures of civilization. Participants are introduced to basic principles of collaborative literacy – how the collaborative mindset can be used to solve wicked problems.

This workshop is intended for people interested in immersion, hands-on skills training and practical results. We are especially seeking participants with an entrepreneurial mindset to expand open source production into the mainstream. We are exploring the potential of open source economics by determining the limits of social production: can distributed, collaborative, community supported manufacturing (CSM) be an alternative to centralized factories? The overall workshop is designed for people interested in transitioning from consumer to producer. We welcome both complete novices and those with experience. The critical part is willingness to learn.

By joining this workshop, you have an opportunity to be part of a community interested in developing products collaboratively and open source, so that everyone can benefit. OSE’s goal is to promote right livelihood using open source – and part of that is starting enterprises. We are promoting the concept of distributive enterprise.

Have questions? Drop us an email: info at opensourceecology dot org

LEARNING OUTCOMES

SCHEDULE

Note: schedule is being refined and may change slightly. The full program goes from 8 AM to 8 PM each day.

Overview

The first day will be dedicated to both metal fabrication workshop skills and design/CAD skills – as ‘basic training’ for the workshop ahead. The first day is designed as a deep dive into the OSE design/build process. We will provide a crash course in FreeCAD – the open source CAD software as a start in the morning. The participant will learn to use the OSE Part Library – to understand the workflow of design – and to make simple designs in FreeCAD. For anyone taking this option, we recommend strongly that you watch and study our 2 FreeCAD tutorial videos to get the most out of the day. While no prior experience is necessary – it will help greatly the more you study up on FreeCAD. We will spend a first hour doing FreeCAD exercises – culminating in the use of the OSE Part Library to make simple tractor designs. We will covere the basic design of a tractor -so that people understand how to create designs and modifications from our Part Library. To facilitate computer work, we recommend that participants download and make a bootable USB drive with our software, as on the OSE Linux page.

We will divide the first day into both design and hands-on training. The morning will focus on the design work – and in the late afernoon, we will do basic training in the shop – consisting of a 3 hour crash lessons on welding, torching, and hand tools. It will be a full day.

Those who do not participate in the first day of skills training will still be able to participate in the workshop – but we do recommend this training for those who would like to get the most out of your experience by being more prepared.

The core of the workshop will be Friday-Sunday – when the 2 tractors will be built. The last day is a bonus where we will test the other tractor modules (solar tractor, automation, gasifier).

Day 1:

• 8 AM: OSE + Event Introduction
• 9 AM: FreeCAD basics. Practicing FreeCAD. Manipulating the CAD. Navigating in tree view. Redesigning components from sketches. Generating technical drawings.
  Using the OSE Part Library.
• 10:45 AM: – Break.
• strong>11 AM:11-Noon – Design Session.
• Lunch
• 1-2:30 PM: Design Session 2: working from the Part Library to generate complete CAD of a tractor.
• 3:00-6:30 PM: Safety training, Crash course in welding, torching, grinding, and hand tools.
• 6:30 PM: Dinner
• 7:30-8:30 PM: (Optional) Material preparation/layout for the workshop.

Day 2:

• 8 AM: Main OSE Introduction
• 9-12 AM: Workshop safety, and beginning of build. Work on Power Cubes, tracks, frames, loaders, and hydraulics.
• Lunch
• 1-6: Afternoon Build Session.
• Dinner
• 7-8 PM: Review and Discussion. Q&A.

Day 3:

• 8 AM: Morning learning session
• 9-12 AM: Finishing Power Cubes.
• Lunch
• 1-6: Afternoon Build Session. Finishing frames, parts, and modules.
• Dinner
• 7-8 PM: Review and Discussion. Q&A.

Day 4:

• 8 AM: Morning learning session
• 9-12 AM: Beginning of overall tractor assembly for both tractors.
• Lunch
• 1-6: Finishing assembly. First runs of tractors.
• Dinner
• 7-8 PM: Review and Discussion. Q&A.

Day 5:

• 8 AM: Morning learning session: Automation, Solar Tractors, Gasifiers
• 9-12 AM: Build of gasifier, solar power cube, automation controller.
• Lunch
• 1-6: Continuing build. Adding the completed modules to the tractor and testing them.
• Dinner
• 7-8 PM: Review and Discussion. Q&A.
